HD-SWTC404: The HDMI 1.4 High Speed switch supports features from the HDMI 1.4 High Speed with Ethernet standard. Supports four HDMI inputs with one HDMI output with built in HDCP engine for fast switching. Features- HDMI 1.4 High Speed with Ethernet
- 3D Support
- Audio Return Channel
- Ports
- 4x HDMI input ports
- 1x RJ45 Ethernet Input
- 1x HDMI output port
- 1x TOSLink Optical ARC output
- 1x Phono digital coaxial ARC output
- 1x 3.5mm socket, stereo output from source device.
Specifications - Supports 1080p 24/50/60Hz
- Built in HDCP support
- 340MHz bandwidth 3.2Gbps per channel (10.2Gbps total)
- Supports 12bit per channel deep colour (36bit in total)
- Support Audio Return Channel (ARC)
- Supports uncompressed audio
- Supports compressed audio
- Supports digital audio Toslink and Coaxial output simultaneously and Stereo audio output from source device.
- Supports CEC
Package Contents - 4 Port HDMI switch
- User manual
- Power supply
- Remote control
|
